Key facts
- Manuals
- 140
- Models
- 1
- Categories
- 2
- Languages
- ZH
- Last added
- 2012-04-10
Beijing阿尔泰发展 models by category
Featured Beijing阿尔泰发展 manuals
Beijing Asitai Technology DAM6018 Data Acquisition Module User Manual
This manual describes the DAM6018 data acquisition module, part of the DAM6000 series, and explains its intended use for measuring voltage, current, temperature and other signals. It includes terminal distribution, connection methods, and performance characteristics.
Key specifications such as 16‑bit resolution, 2 MΩ input impedance, ±0.1% accuracy, and a 12 W power consumption are listed, along with recommended wiring and signal conditioning details. This manual is written in Chinese.
Covers: Introduction · Terminal Distribution · Connection Methods · Signal Input Ranges · Performance Specifications
Beijing art-control technology DAM-3030 Manual
This manual describes the DAM-3039F data acquisition module, which offers up to six differential channels, two single‑ended channels, and optional eight‑channel differential mode. The module features 16‑bit resolution, 0.1% accuracy, and a 20 MΩ input impedance, with low temperature drift and high isolation voltage.
Power is supplied at 24 VDC with a consumption of 0.8 W. The device supports RS‑485 communication, multiple baud rates (1200‑115200 bps), and a variety of input ranges from 15 mV to 2.5 V. Terminal assignments and wiring diagrams are provided for proper installation and operation. This manual is written in Chinese.
Covers: Technical Specifications · Input Range and Accuracy · Channel Configuration · Power Supply · RS‑485 Interface · Terminal Assignments
Beijing Altai Technology USB5538 Optical Isolation DI/DO Card User Manual
The USB5538 card is a USB‑bus data acquisition device offering 16 isolated digital inputs and 16 isolated open‑collector digital outputs. It is suited for laboratory testing, product quality inspection, and industrial process monitoring.
The manual covers functional overview, component layout, detailed pin‑out tables for DI and DO connectors, wiring methods for dry and wet contacts, installation guidance, and warranty terms. It also includes a physical ID dip‑switch configuration guide and LED status indicators. This manual is written in Chinese.
Covers: Function Overview · Component Layout and Description · Signal Input/Output Connectors · Signal Connection Methods · Installation Guidance · Application Notes, Calibration, Warranty
Beijing Alta Technology ZIGBEE1080A ZigBee Module User Manual
The ZIGBEE1080A is a transparent data‑transfer module that can be connected to RS232 or RS485 devices to form a ZigBee network. It supports both API (default) and AT working modes, can act as an end‑node or a server, and offers automatic routing for extended network distances.
The document provides details on the module’s physical connectors, LED indicators, dip‑switch settings, power requirements, performance specifications, and important usage precautions such as power supply, PAN ID matching, baud‑rate configuration, and hop limits. This manual is written in Chinese.
Covers: Module Function Overview · Module Structure and Wiring Terminals · LED Indicators · Dip Switch Settings · Performance Specifications · Usage Precautions
Latest Beijing阿尔泰发展 manuals
Beijing art-control technology PCI8025 DAQ Card hardware Manual
This manual details the hardware functions, connection methods, usage precautions and other information of the PCI8025 data acquisition card
Beijing art-control technology ARM8006 user manual
Beijing art-control technology PCI1010 motion control card hardware Manual
The PCI1010 motion control card is a hardware device provided by Beijing Alta Technology Development Co., Ltd. The control card features a 32-bit PCI bus interface and can be used for 2-axis servo/stepper motor control. It supports pulse output with a frequency error less than 0.1% and a maximum speed of 4 MHz. Additionally, it offers various pulse output modes, asymmetric linear acceleration/deceleration drive, and various interpolation functions. The control card also supports fixed linear speed control, multi-axis synchronous start/stop, and more.
Beijing Asitai Technology DAM6018 Data Acquisition Module User Manual
User Manual 3 pages · 95 KB · ZHThe user manual provides setup, connection methods, and specifications for the DAM6018 data acquisition module by Beijing Asitai Technology.
Beijing art-control technology DAM-3030 Manual
User Manual 4 pages · 119 KB · ZHThe user manual for Beijing Asitai Technology's DAM-3039F data acquisition module provides specifications, wiring, and operation instructions.
Beijing Altai Technology USB5538 Optical Isolation DI/DO Card User Manual
User Manual 11 pages · 322 KB · ZHThe USB5538 optical isolation DI/DO card manual provides hardware overview, installation steps, connector definitions, and warranty information.
Beijing Alta Technology ZIGBEE1080A ZigBee Module User Manual
User Manual 3 pages · 124 KB · ZHThe manual describes the features, wiring, configuration and operation of the ZIGBEE1080A transparent data transmission module.
Beijing Altai Technology DAM6013 Data Acquisition Module User Manual
User Manual 3 pages · 105 KB · ZHUser manual for the Beijing Altai Technology DAM6013 data acquisition module, covering specifications, wiring, and configuration.
Beijing Altai DAM-3503/T Data Acquisition Module User Manual
User Manual 3 pages · 155 KB · ZHThe Beijing Altai DAM-3503/T data acquisition module user manual provides specifications, wiring diagrams, and configuration details.
Beijing Altai Technology DAM-3505/T Data Acquisition Module User Manual
User Manual 3 pages · ZHThe Beijing Altai Technology DAM-3505/T data acquisition module user manual provides specifications, wiring diagrams, and configuration details.
Beijing Azhusuo Technology AGPRS1080 User Manual
User Manual 20 pages · 513 KB · ZHUser manual for the AGPRS1080 GPRS module covering installation, configuration, and operation.
Beijing Art-Control Technology ZigBee1081 Wireless DAQ Card User Manual
User Manual 16 pages · 402 KB · ZHHardware usage manual for the ZigBee1081 wireless data acquisition card, covering specifications, installation, and operation.
Altai PCI8622 Data Acquisition Card User Manual
User Manual 34 pages · 1.9 MB · ZHHardware user manual for the Altai PCI8622 data acquisition card, covering features, connections, and calibration.
Beijing art-control technology PCI2600 WIN2000/XP drive program Manual
Beijing art-control technology pci8622 DAQ Card software Manual
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Beijing阿尔泰发展 manuals
What is the input impedance of the DAM6018 module?
The module has an input impedance of 2 MΩ.
From: Beijing Asitai Technology DAM6018 Data Acquisition Module User Manual
What resolution does the DAM6018 provide?
It provides a 16‑bit resolution.
From: Beijing Asitai Technology DAM6018 Data Acquisition Module User Manual
What is the resolution of the DAM-3039F module?
The module provides a 16‑bit resolution.
How many differential channels does the module have?
It includes six differential channels, plus additional single‑ended or differential options.
How many digital input channels does the USB5538 card provide?
The card provides 16 isolated digital input channels.
From: Beijing Altai Technology USB5538 Optical Isolation DI/DO Card User Manual
What is the isolation voltage rating for the inputs and outputs?
Both the inputs and outputs have an isolation voltage rating of 3750 V.
From: Beijing Altai Technology USB5538 Optical Isolation DI/DO Card User Manual
