This document is the operation manual of LA6-POE signal tower, which introduces the product features, installation, connection and usage methods.
This document is the Operation Manual for the PATLITE LA6-POE Signal Tower. It details the product features, including the 'Smart Mode' function which allows for various displays like slow flashing or level meter simulation, in addition to standard Signal Tower Mode. The device supports Power over Ethernet (PoE) and can be controlled via LAN cable to acquire status conditions and manage settings remotely.
The manual covers installation procedures for direct-mount and stationary types, wiring instructions for terminal blocks and LAN cables, and operating procedures for controlling the unit via commands or signal line inputs. It also includes sections on network setup, LED unit configuration, mirroring functions, and troubleshooting.
| Rated Voltage | DC24V |
|---|---|
| Power Supply | PoE Supported |
| Control Methods | Signal line input / LAN Cable |
Smart Mode allows for various displays such as a slow flashing rate, simulating a firefly, and a display that can be used as a level meter.
Yes, since it is compatible with Power over Ethernet (PoE), it can be operated through a LAN Cable to acquire signal tower status conditions via the network.
The rated voltage is DC24V.
