Eaton LM5S Technical Environment Systems Installation Manual

This is an installation manual that introduces the assembly method of Wright Line's Technical Environment Systems


Eaton LM5S Technical Environment Systems Installation Manual - cover page
Brand
Eaton
Category
Office Equipment
Document type
Installation Guide
Language
English
Pages
202
File format
PDF
File size
2.7 MB
Published
16 October, 2023
Updated
16 October, 2023
MD5 checksum
A980C1D23198BBABCDA3A24EFAC5C6F2

About this manual

The document serves as an installation guide for the Eaton LM5S Technical Environment Systems. It covers the assembly of full frames, open frames, and uprights, detailing the required tools and step-by-step procedures for constructing various frame sizes from 24 inches to 96 inches wide.

The manual also provides instructions for installing additional components such as worksurfaces, keyboard holders, shelf systems (steel and laminate), locking compartments, cable management accessories, power management solutions, and lighting. It includes specific parts lists with part numbers and descriptions for different frame configurations and support tubes.

What's inside

  • Introduction
  • Tools Required
  • Full Frame Assembly
  • Upright Assembly
  • Worksurface Installation
  • Shelf Components
  • Cable Management Accessories
  • Power Management Accessories
  • Lighting Accessories
  • Parts List

Specifications

Frame Widths Available24", 30", 36", 42", 48", 60", 72", 90", and 96"
Publication DateMay 2018

Frequently asked questions

What tools are required for assembly?

Required tools include a tape measure, Phillips head screwdriver, Allen wrenches (5/32" and 1/4"), plastic mallet, 1/2" wrench, level, and leveling wrench.

What tools are required to assemble the frame and uprights?

You need a tape measure, Phillips head screwdriver, Allen wrenches (5/32" and 1/4"), a plastic mallet, a 1/2" wrench, a 2 to 3 foot level, and a leveling wrench.

How are the support tubes attached to the frame?

Drive a #10-24 x 3/8" screw through the channel into the pre-drilled hole in the support tube on both sides of the joint, then bolt the tubes in place with 5/16"-18x 1.00 cap screws and washers.
