This manual introduces the features of the HighPoint RocketRAID 4520/4522 series, including specifications, installation, configuration, and usage methods.
The HighPoint RocketRAID 4520/4522 Series User Manual guides users through setting up the hardware, installing drivers, and configuring RAID arrays using the WebGUI, BIOS, or Command Line Interface. It covers both the 4520 and 4522 models, which support up to 8 drives and various RAID levels including RAID 0, 1, 5, 6, and JBOD.
| I/O Processor | 6Gb/s RAID -on-Chip |
|---|---|
| Cache Memory | 512MB DDR3 Cache memory with ECC protection |
| Number of Device Ports | 8 6Gb/s SAS & SATA ports |
| Host Bus Interface | PCI Express 2.0 x8 |
| RAID Feature Suite | RAID 0, 1, 5, 6, 1/0, 5/0, JBOD |
| Operating Temperature | +5°C ~+55°C |
| Operating Voltage | 12 V / 3.3 V |
The box includes the Host Bus Adapter, Driver CD, Low profile bracket, and Quick Installation Guide. Cables and Battery Backup Unit are sold separately.
The controller supports Windows 10, Windows Server 2016, major Linux distributions, FreeBSD, and Mac OS X 10.6.x and later.
Supported RAID levels include RAID 0, 1, 5, 6, 1/0, 5/0, and JBOD.
