Featured HighPoint manuals
HighPoint SSD7103 & SSD7202 Data RAID Installation Guide (Linux)
This guide covers hardware and software prerequisites, UEFI BIOS configuration, driver and management software installation, updates, and removal procedures for the HighPoint SSD7103 and SSD7202 data RAID controllers. It also provides detailed troubleshooting steps and information on collecting logs for support.
The document includes step‑by‑step commands for verifying controller detection, compiling drivers, and configuring the system BIOS, as well as instructions for using the HighPoint RAID WebGUI and CLI tools.
Covers: Overview · Prerequisites for Data RAID Configuration · UEFI BIOS Settings · Driver Installation · Installation · Update
HighPoint RocketRAID 3520 Serial ATAII Adaptation Card User Manual
The RocketRAID 3520 is an 8‑channel PCI‑E to Serial ATAII RAID controller designed for enterprise storage applications such as NAS, workgroup servers, video editing workstations, and data backup. It features Intel I/O processing, ECC‑protected DDRII memory, and support for multiple RAID levels.
This user guide covers hardware description, installation procedures, BIOS configuration, operating‑system driver installation for Windows, Linux, and macOS, the Web‑RAID management interface, and troubleshooting information, including battery‑backed backup and LED indicators. This manual is written in Chinese.
Covers: Adapter Introduction · Features and Specifications · RAID Concepts and Terminology · Hardware Description / Installation · BIOS Configuration Utility · Windows Installation
HighPoint RocketRAID 1640 User Manual
The RocketRAID 1640 is a 4‑channel ATA133 RAID adapter that can connect up to eight IDE disks and supports RAID 0, 1, 10, 5 and JBOD. It offers hot‑swap capability, spare‑disk support, and a maximum disk capacity of 137 GB.
The manual covers physical installation of the adapter card, BIOS configuration utility usage, driver installation for Windows and Linux operating systems, RAID management software instructions, and a troubleshooting appendix. Appendices include a glossary of RAID terms and technical support contact information. This manual is written in Chinese.
Covers: Overview · Adapter Card Installation · BIOS Configuration Utility · RAID Management Software · Driver Installation · Troubleshooting
Latest HighPoint manuals
HighPoint SSD7103 & SSD7202 Data RAID Installation Guide (Linux)
Installation Guide 20 pages · 1.1 MB · ENGuide for installing, updating and troubleshooting HighPoint SSD7103 and SSD7202 NVMe RAID controllers on Linux systems.
highpoint RocketRAID 1820/1820A chinese Manual
HighPoint RocketRAID 3520 Serial ATAII Adaptation Card User Manual
User Manual 60 pages · 1.1 MB · ZHThe manual provides specifications, installation steps, BIOS configuration, driver support, and RAID management for the HighPoint RocketRAID 3520 Serial…
HighPoint RocketRAID 1640 User Manual
User Manual 37 pages · 1.7 MB · ZHThe HighPoint RocketRAID 1640 User Manual provides installation, BIOS configuration, driver setup, and troubleshooting for the ATA133 RAID controller.
HighPoint Technologies Inc. RocketRAID 2220 SATAII Disk array card Manual
RocketRAID 2220 SATAII Disk Array Card User's Manual introduces the features of the product and the instructions for installation, configuration and maintenance of disk arrays
Which document do I need?
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in HighPoint manuals
What BIOS settings are required for the SSD7103/SSD7202 RAID controller?
The motherboard must use UEFI BIOS, the PCIe slot OPROM must be set to EFI, and Secure Boot must be disabled.
From: HighPoint SSD7103 & SSD7202 Data RAID Installation Guide (Linux)
How can I verify that the SSD7103/SSD7202 controller is detected in Linux?
Open a terminal with root privileges and run commands such as lspci, fdisk -l, and dmesg | grep nvme to check for the controller and attached SSDs.
From: HighPoint SSD7103 & SSD7202 Data RAID Installation Guide (Linux)
Which operating systems are supported by the RocketRAID 3520?
The adapter supports Windows (2000, XP, 2003, Vista 32/64‑bit), Mac OS X 10.4‑x and 10.5‑x, Linux kernels 2.6 and later, and FreeBSD.
From: HighPoint RocketRAID 3520 Serial ATAII Adaptation Card User Manual
How many SATA II channels does the RocketRAID 3520 provide?
It provides eight SATA II channels, each capable of 3 Gb/s.
From: HighPoint RocketRAID 3520 Serial ATAII Adaptation Card User Manual
How do I install the RocketRAID 1640 adapter card?
Power off the computer, discharge static, open the case, insert the RocketRAID 1640 card into a PCI slot, secure it with screws, connect the power cable, close the case and power the system back on.
Which operating systems are supported by the RocketRAID 1640?
The controller works with Windows 9x/ME/NT4.0/2000/XP, Linux distributions such as Red Hat, SuSE, Turbo and Caldera, and FreeBSD.
