ITT Model 3409 Pump Installation Operation and Maintenance Manual

About this manual

This document serves as the official guide for the ITT Model 3409 pump, providing comprehensive instructions for installation, commissioning, and daily operation. It includes critical safety warnings regarding pressure, hazardous fluids, and proper electrical connections to prevent injury or equipment damage.

What's inside

• Introduction and Safety
• Transportation and Storage
• Product Description
• Installation
• Commissioning and Operation
• Maintenance
• Troubleshooting
• Parts List
• Technical Reference

Frequently asked questions

What safety equipment must be worn when handling the pump?

Operators must wear a hardhat, safety goggles with side shields, protective shoes, protective gloves, a gas mask, and hearing protection.

What is the maximum allowable sound pressure level in the operating area?

Sound pressure levels may exceed 80 dbA in operating process plants.

What happens if the pump is operated with the suction valve closed?

Operating the pump with the suction valve closed is prohibited and can cause heat and pressure buildup leading to explosion or rupture.
