The S2F.PORT 2.0 is a protocol converter that can be used to integrate both S.Port and SBUS signals, and translate into multiple F.Port 2.0 signal outputs for controlling up to 8 F.Port 2.0 capable servos simultaneously.
The FrSky S2F.PORT 2.0 is a protocol converter designed to integrate S.Port and SBUS signals, translating them into multiple F.Port 2.0 signal outputs. This allows for the simultaneous control of up to 8 F.Port 2.0 capable servos. When paired with an SBUS and S.Port capable receiver, it enables telemetry features, such as current and voltage feedback, for connected Xact servos via the F.Port 2.0 protocol.
| Dimension | 53*21*12mm |
|---|---|
| Weight | 10g |
| Servo Channels | 9 Servo Channels |
| Max Servos | 8 F.Port 2.0 capable servos |
It is a protocol converter used to integrate both S.Port and SBUS signals and translate them into multiple F.Port 2.0 signal outputs.
The device can control up to 8 F.Port 2.0 capable servos simultaneously.
The LED indicates the state of the SBUS and S.Port connections (On or On/Flash).
