FrSky Smart Port Current Sensor – FAS100S is a smart current sensor for FrSky Smart Port system, which can measure current (A) and battery voltage (V) when connected between a Battery and ESC and it has two temperature sensors.
The FrSky FAS100S is a Smart Port Current Sensor designed for use with FrSky Smart Port enabled systems. It measures current and battery voltage when connected between a battery and an Electronic Speed Controller (ESC), and includes two temperature sensors. The device features an XT90 Anti spark connector and is compatible with FrSky Smart Port enabled receivers.
| Measured Range (Temperature) | -20°C~250°C / -4 °F~482 °F |
|---|---|
| Deviation | 5% |
| Dimension | 65mm * 21mm = 18mm (LxWxH) |
| Weight | 26g |
| Measurement range | 0~100A |
| Current consumption | 27mV@5V |
| Maximum safe current | 100A |
| Maximum battery voltage | 14S |
| Connector | XT90 Anti spark |
The default physical ID for this sensor is 07.
A red flash indicates NO connection, while a green flash indicates YES connection.
Yes, all FrSky Smart Port enabled sensors could daisy chain with each other through their Smart Port.
