FrSky Smart Port Current Sensor – 40A is designed for FrSky Smart Port enabled system, and can measure Current (A) and Battery Voltage (V) when connected between a Battery and ESC.
The FrSky Smart Port Current Sensor – 40A is designed to measure current (A) and battery voltage (V) when connected between a battery and an Electronic Speed Controller (ESC). It is compatible with FrSky Smart Port enabled receivers such as the X8R, X6R, and X4R. The sensor features a maximum safe current of 40A and supports up to 6S battery configurations.
| Measurement range | 0~40A |
|---|---|
| Current consumption | 25mA@5V |
| Maximum safe current | 40A |
| Maximum battery voltage | 6S |
The default physical ID for this sensor is 03.
It is compatible with FrSky Smart Port enabled receivers, such as X8R, X6R, and X4R.
