Scout VS600 is a lightweight and compact high-definition digital video transmission device launched by FrSky. It supports S.Port and reversed S.Port and has an internal microphone that supports 600mW power output
The FrSky Scout VS600 Series is a high-definition digital video transmission device designed for use with FrSky radio transmitters. The series includes three models: Scout VS600 RED, Scout VS600 BLACK, and Scout VS600 Mini. These devices feature switchable power output and operating bands/channels, allowing users to adjust parameters conveniently via the gTrans.lua script or manual button configuration.
| Model Name | Scout VS600 RED, Scout VS600 Black, Scout VS600 Mini |
|---|---|
| Dimensions (RED) | 31.5*23.6*4.5 mm |
| Weight (RED) | 42 g |
| Operating Voltage | 2-65 V |
| Transmission Frequency | 5.7 GHz |
| Transmission Power (Pit mode) | <0.01mW |
| Transmission Power (Max) | 600 mW |
Only the Scout VS600 BLACK and Scout VS600 RED models support 600 mW power output.
Parameters can be adjusted conveniently through the gTrans.lua script or by using the button for manual configuration.
Yes, the Scout VS600 RED and BLACK models have a built-in microphone which transmits audio.
