The document describes the ANT2-M24LR-A, a ready-to-use printed circuit board (PCB) featuring an etched 13.56 MHz inductive antenna and an M24LR64-R Dual Interface EEPROM IC. This reference board connects to an I²C bus on one side and includes a 20 mm x 40 mm antenna, allowing system designers to evaluate the performance and capabilities of the M24LR64-R IC.
The board measures 20 mm by 40 mm.
The antenna operates at 13.56 MHz.
