Introduces the Kyman-NET™ vehicle cradle features, including electrical, communication, environmental and mechanical features
The Datalogic Kyman-NET Vehicle Cradle is designed to hold and charge the Kyman-NET mobile computer while securely mounting it in a vehicle. It also functions as a serial communication interface between a Host, typically a Laptop PC, and the RS232 contacts on the mobile computer.
This document covers the installation of the cradle using an adjustable arm kit or screws, wiring instructions for connecting to the vehicle's 10-32 VDC power source with an in-line fuse, and procedures for inserting and extracting the mobile computer. It also details how to configure vocal communication settings on the mobile computer.
| Power Supply Range | 10 to 32 VDC |
|---|---|
| Consumption (with mobile computer) | Max. 1.8A |
| Quiescent Consumption | Max. 5 mA |
| Baud Rate | up to 115200 b/sec |
| Working Temperature | -20° to +50 °C / -4° to +140 °F |
| Storage Temperature | -20° to +70 °C / -4° to +158 °F |
| Degree of Protection | IP20 |
| Dimensions | 118.5 x 321 x 104 mm / 4.66 x 12.63 x 4.09 in |
| Weight | about 770 g/ 27.16 oz |
The cradle requires a power supply from 10 to 32 VDC.
The maximum consumption with the mobile computer is 1.8A.
Vocal communication requires Kyman-NET Mobile Computer SW version 1.34 or later.
