The Extech 382100 3-Phase Power Analyzer/Datalogger has a large screen, full system analysis, high accuracy autoranging current clamps, 600VAC input and CAT III-600V safety rating, and can record up to 30,000 readings and save them in Excel format on a removable SD memory card.
The Extech 1200A is a 3-phase power analyzer and datalogger designed for AC power quality evaluation, motor/generator installation, and energy audits. It features a large backlit LCD display capable of performing full system analysis with up to 35 parameters, including voltage, current, active/reactive/apparent power, power factor, frequency, and phase angle.
| AC Voltage Range (True rms) | 600.0V ±(0.5%rdg+0.5V) |
|---|---|
| Current Range | 1200A ±(0.5%rdg+0.5A) |
| Active Power Range | 9.999MW ±(1.0%rdg+0.08KW) |
| Frequency Range | 45Hz to 65Hz ±0.1Hz |
| Phase Angle Range | -180° to +180.0° ±1° |
| Datalogging Capacity | 60,000 readings (2GB SD memory Card) |
| CAT Rating | CAT III-600V |
The device supports a high accuracy autoranging current clamp from 0.2A to 1200A.
Data is saved on an SD card in Microsoft Excel® format for easy transfer to a PC.
