This document is the MAX II Device Handbook from Altera Corporation, which describes the features and characteristics of their programmable solutions products.
This document serves as a comprehensive technical reference for the Altera MAX II device family, specifically model MII5V1-3.3. It details the internal architecture including Logic Array Blocks (LABs) and Logic Elements (LEs), as well as I/O structures and standards.
The handbook provides extensive information on in-system programmability (ISP), JTAG boundary-scan testing, and user flash memory usage. It also includes detailed DC and switching characteristics, package outlines for various pin counts, and guidelines for using these devices in multi-voltage systems.
The device operates with a supply voltage between 2.375 V and 3.625 V.
You must use JTAG signals to perform programming or erasing operations on the UFM.
