The R1114x Series are CMOS-based LDO regulators featuring 150mA output. High ripple rejection and excellent load transient response of the series make the product ideally suited for use in power source for hand-held communication equipment.
The R1114x Series are CMOS-based LDO regulators featuring a 150mA output. The series is characterized by high ripple rejection and excellent load transient response, making it ideally suited for use as a power source for hand-held communication equipment. The polarity of the CE pin can be selected, and an auto-discharge function is available.
| Output Current | 150mA |
|---|---|
| Standby Current (Typ) | 0.1uA |
| Dropout Voltage (Typ) | 0.22V |
| Ripple Rejection (Typ @ 10kHz) | 60dB |
| Input Voltage Range | 0V to 6.0V |
| Output Voltage Range | 1.5V to 4.0V |
| Output Voltage Accuracy | 2% |
| Temperature Coefficient | Typ. +100ppm/°C |
Yes, ceramic capacitors can be used for this series.
The series features a 150mA output.
Ceramic capacitors can be used for the circuit.
The typical dropout voltage is 0.22V under those conditions.
