1PS88SB48 is a Schottky barrier diode produced by Philips company. It has ultra fast switching speed, low forward voltage, small SMD package and guard ring protection. It is used in high speed switching, circuit protection and voltage clamping.
The Philips 1PS88SB48 is a discrete semiconductor component consisting of two dual high-speed switching diodes with common cathodes. These devices are fabricated using planar technology and encapsulated in a small SMD SC-88 plastic package, designed for applications requiring ultra-fast switching speeds.
| Continuous reverse voltage (Vr) | - 40 V |
|---|---|
| Continuous forward current (Ir) | - 120 mA |
| Repetitive peak forward current | - 120 mA |
| Non-repetitive peak forward current | - 200 mA |
| Storage temperature (Tstg) | -65 +150 °C |
| Junction temperature (Tj) | - 150 °C |
| Diode capacitance (Cy) | 5 pF |
The device is suitable for high speed switching, circuit protection, and voltage clamping.
No, these products are not designed for use in life support appliances or devices where malfunction can result in personal injury.
