AMD SR5650 Databook Technical Reference Manual

This document is AMD SR5650 datasheet, which mainly contains product's technical characteristics, specifications, functions, etc.

Brand: AMD
Category: other commodities
Document type: Datasheet
Language: English
Pages: 78
File format: PDF
File size: 968 KB
Published: 09 July, 2012
Updated: 01 October, 2023
Model: SR5650
MD5 checksum: A6A9D5EF55BEE379F253A5325B88EAFA
PDF: AMD SR5650 Databook Technical Reference Manual PDF

About this manual

The AMD SR5650 Databook serves as a technical reference manual for the SR5650 chipset, detailing its architecture and interface capabilities. Key features include support for multiple processors and Northbridges, HyperTransport™ and PCI Express® interfaces, and various power management functions. The document outlines compliance with PC Design Guide standards and includes specific test capability features for system integrators.

What's inside

SR5650 Features
HyperTransport Interface
PCI Express Interface
Pin Descriptions
Timing Specifications
Electrical Characteristics
Power Management
Testability Features

Specifications

Part Number	47062_sr5650_ds_pub
Revision	2.10
Copyright Year	2011

Frequently asked questions

What is the part number of this manual?

The document's part number is 47062_sr5650_ds_pub.

When was the latest revision of this manual released?

Revision 2.10 was released in June 2011.

What is the package type for the SR5650 processor described here?

The SR5650 uses a 692-pin FCBGA package.
