AMD SB600 Register Reference Manual

About this manual

This document serves as a technical reference guide for the AMD SB600 Southbridge, designed to operate with AMD's RADEON IGP Xpress family of integrated graphics processor products. It integrates key input/output (I/O), communications, and audio features required in state-of-the-art PCs.

What's inside

• Introduction
• Register Descriptions: PCI Devices
• SATA Registers
• USB Controllers
• SMBus Module
• IDE Controller
• AC'97 Controller
• HD Audio Controllers
• PCI Bridges
• General Purpose Functions

Frequently asked questions

What CPUs is the AMD SB600 designed to operate with?

The device operates with AMD's RADEON IGP Xpress family of integrated graphics processor products in both desktop and mobile PCs.

What are the supported USB speeds for this controller?

All 10 ports support USB 1.1 Low Speed, Full Speed, and USB 2.0 High Speed compatibility.

How many SATA ports does the controller support?

The controller supports four SATA ports complying with the SATA 2.0 specification.
