74F804/1804 is a 2-input NAND driver with high capacitive drive capability produced by Philips Semiconductors. It has a typical propagation delay of 2.5ns and a typical supply current of 9mA.
This datasheet provides product specifications for the Philips 74F804 and 74F1804 Hex 2-input NAND drivers. The 74F804 features corner Vcc and GND pins, while the 74F1804 features center Vcc and GND pins. Both devices offer a typical propagation delay of 2.5ns and high capacitive drive capability.
| Typical propagation delay | 2.5ns |
|---|---|
| High-level output current | -48 mA |
| Low-level output current | 48 mA |
| Package type (74F804) | 20-pin plastic DIP |
The 74F804 has corner Vcc and GND pins, while the 74F1804 has center Vcc and GND pins.
The typical propagation delay for both devices is 2.5ns.
