BUK219-50Y is a single channel high side protected power switch manufactured by Philips Semiconductors using TOPFET2 technology, packaged in a 5-pin plastic package.
The Philips BUK219-50Y is a monolithic single-channel high-side switch utilizing TOPFET2 technology, housed in a 5-pin plastic SOT263B package. It is designed to drive lamps, motors, solenoids, and heaters, offering a nominal load current of 2 A and a continuous load current of up to 6 A.
| Nominal load current (ISO) | 2 A |
|---|---|
| Continuous load current | 6 A |
| Continuous off-state supply voltage | 50 V |
| Continuous junction temperature | 150 ˚C |
| On-state resistance (Tj = 25˚C) | 180 mΩ |
| Package type | 5 pin plastic package |
The maximum continuous load current is 6 A.
The maximum continuous off-state supply voltage is 50 V.
