LMC2001 is a high precision, 6MHz rail-to-rail output operational amplifier, with excellent CMRR and PSRR, low 1/f noise, low supply current, wide gain-bandwidth product.
The LMC2001 is a high precision operational amplifier offered by National Semiconductor in miniature SOT23-5 and SOIC packages. It utilizes patented techniques to measure and correct input offset error voltage, ensuring ultra-stability over time and temperature. Key features include a wide gain-bandwidth product of 6MHz, a slew rate of 5V/µs, and a low supply current of 750µA.
| Gain-Bandwidth Product | 6 MHz |
|---|---|
| Slew Rate | 5 V/µs |
| Supply Current | 750 µA |
| Output Swing | 30mV from either rail |
| Common Mode Rejection Ratio | 120 dB |
| Power Supply Rejection Ratio | 120 dB |
| Large Signal Voltage Gain | 137 dB |
| Operating Temperature Range (Industrial) | -40°C to +85°C |
| Operating Temperature Range (Commercial) | 0°C to +70°C |
The LMC2001 has a low supply current of 750µA.
No, the LMC2001 does not require external capacitors.
The device is available in 5-pin SOT23 and 8-pin SOIC packages.
