The TDA1519 is an integrated class-B dual output amplifier in a 9-lead single in-line (SIL) plastic medium power package, primarily developed for car radio applications. It features high output power, requires very few external components, has good ripple rejection, mute/stand-by switch, load dump protection, AC and DC short-circuit-safe to ground and VP, thermal protection, reverse polarity safe, capability to handle high energy on outputs (VP = 0 V), no switch-on/switch-off plop, and is protected against electrostatic discharge.
The Philips TDA1519 is an integrated class-B dual output amplifier designed primarily for car radio applications. It features a fixed gain of 40 dB and includes a mute/stand-by switch with low current consumption in standby mode. The device is thermally protected and safe against AC and DC short circuits, as well as reverse polarity.
| Output Power | 2 x 6 W |
|---|---|
| Supply Voltage Range | 6.0 to 18.0 V |
| Total Quiescent Current | 40 to 80 mA |
| Switch-on Current | < 40 uA |
| Supply Voltage Ripple Rejection | 48 dB |
| Package Type | 9-lead SIL plastic |
The gain of each amplifier is fixed at 40 dB.
Yes, it is compatible with the TDA1517, except for the gain.
