TDA1522 is a playback amplifier for car radio/cassette players. It features two independent amplifiers with an open-loop gain of 90 dB (typical), internal DC feedback via a 140 kΩ resistor, AC characteristics determined by an external RC network, electronic on/off switching with transient suppression, head input at DC ground, minimum external component requirement, stability down to a gain of 30 dB, low input noise and distortion, and a wide supply voltage range.
The TDA1522 is an integrated circuit designed as a playback amplifier for car radio and cassette players. It features two independent amplifiers with an open-loop gain of 90 dB (typical) and includes internal DC feedback via a 140 kΩ resistor. The device offers electronic on/off switching with transient suppression and is designed for stability down to a gain of 30 dB with minimum external component requirements.
| Supply voltage | 7.6 - 23 V |
|---|---|
| Supply current | 5 mA |
| Operating ambient temperature | -30 to +85 °C |
| Total harmonic distortion | 0.05 % |
| Channel separation | 45 dB |
| Open-loop voltage gain | 90 dB |
The supply voltage ranges from 7.6 V to 23 V.
The maximum total power dissipation is 800 mW.
