TDA1516CQ is a 24W BTL car radio power amplifier with features including few external components required, high output power, low offset voltage, fixed gain, good ripple rejection, mute/stand-by switch, load dump protection, etc.
The Philips TDA1516CQ is a monolithic integrated class-B output amplifier designed primarily for car radio applications. It features a bridge-tied-load (BTL) configuration requiring very few external components and includes a mute/stand-by switch with low current consumption. The device is protected against electrostatic discharge, reverse polarity, and load dumps, ensuring robust operation in automotive environments.
| Output Power | 24 W |
|---|---|
| Supply Voltage Range | 6.0 to 18 V |
| Quiescent Current | 40 to 80 mA |
| Gain | 20 dB |
| Package Type | 13-lead SIL plastic |
| Operating Temperature | -55 to +150 °C |
The device provides 24 W of output power in a bridge-tied-load configuration.
The operating supply voltage range is from 6.0 V to 18 V.
