TDA1516BQ is a 24W single-channel car power amplifier chip produced by Philips. The chip is packaged in a single line and has low power consumption, high output power, and low output distortion.
The Philips TDA1516BQ is an integrated class-B output amplifier designed primarily for car radio applications. It is available in a 13-lead single-in-line (SIL) plastic power package and supports both stereo and bridge-tied-load (BTL) configurations. Key features include reverse polarity protection, load dump protection, and a mute/stand-by switch with low current consumption.
| Output Power (BTL) | 24 W |
|---|---|
| Output Power (Stereo) | 2 x 12 W |
| Supply Voltage Range | 6.0 V to 18.0 V |
| Total Quiescent Current | 30 mA |
| Gain | 20 dB |
| Package Type | 13-lead SIL plastic power package |
| Channel Separation | 40 dB |
The device provides 24 W of output power in bridge-tied-load (BTL) applications.
Yes, the device is reverse polarity safe and can handle up to -6 V.
Yes, it features a mute/stand-by switch with a low stand-by current of less than 100 pA.
