Agilent Cary 630 FTIR is a class-leading spectrometer for industrial applications as well as academic teaching and research support. Its ultracompact size, superior performance, versatility and ease of use make it an ideal choice for users that need a robust spectrometer for everyday, routine use.
The Agilent Cary 630 FTIR is a class-leading spectrometer designed for industrial applications, academic teaching, and research support. It features an ultracompact design with a sealed and desiccated enclosure, making it robust for everyday routine use. The instrument utilizes a unique Flexture-based interferometer and solid-state laser for reliable, accurate, and repeatable results.
| Interferometer | 25 mm, permanently aligned, Michelson, 45°, mechanical flexture |
|---|---|
| Enclosure | Sealed and desiccated |
| Spectrometer interface | USB-2 |
| Size | 16 x 31 x 13 cm (6 x 12 x 5 inches) (W x D x H) |
| Weight | 3.8 kg (8 lbs) |
| Power | 110 — 240 V AC, 60/50 Hz |
| Spectral range (KBr) | 7000-350 cm-1 |
| Spectral range (ZnSe) | 5100-600 cm-1 |
| Spectral resolution | <2 cm-1 |
| Wavenumber accuracy | 0.05 cm-1 |
| Wavenumber reproducibility | 0.005 cm-1 |
| Interferometer warranty | Five (5) year |
| Laser warranty | Five (5) year |
| Source warranty | Three (3) year |
The instrument supports DialPath, TumblIR, Diamond ATR, Diffuse Reflectance, and Transmission.
Yes, the optional Agilent MicroLab PC software is 21 CFR Part 11 compliant.
The spectral range with KBr optics is 7000-350 cm-1.
