This document introduces the features and characteristics of Agilent Reliance Cartridge Guard-Column Series. This series of products provides convenient, cost-effective protection for high-performance analytical columns. Components can be assembled quickly and easily to provide a high-efficiency, low-dead-volume column that seals with hand tightening, against operating pressures up to 5000 psi (340 bar).
The High Performance Agilent Reliance Cartridge Guard-Column Series is designed to provide convenient, cost-effective protection for high-performance analytical columns. The components assemble quickly to create a high-efficiency, low-dead-volume column that seals with hand tightening against operating pressures up to 5000 psi (340 bar).
| Operating Pressure | 5000 psi (340 bar) |
|---|---|
| Column Dimensions | 4.6 mm id x 12.5 mm |
| Void Volume | < 150 µL |
| Maximum Temperature | 60 °C |
Replace the guard cartridge when system pressure has increased by 10% from normal or after every 100 to 200 injections.
Flush a minimum of 3 mL of methanol through the assembly, then flush with 10 mL of mobile phase.
