Agilent 800 MHz PremiumCOMPACT NMR Magnet is a new type of superconducting NMR magnet. It uses the latest superconducting wire technology to operate at 4.2 Kelvin, which saves more laboratory space and is more convenient to use than traditional 800 MHz magnets. It also has lower operating costs.
The Agilent 800 MHz PremiumCOMPACT NMR magnet utilizes superconducting wire technology to operate at 4.2 Kelvin (K). This active shielding eliminates the need for constantly running vacuum pumps found in traditional ~2 K systems, reducing maintenance requirements.
Key benefits include a reduced magnetic footprint of only 6.6 m² and a smaller cryostat that does not require a second helium reservoir. The system features excellent fringe field characteristics and minimized ceiling height to facilitate ease of siting.
| NMR frequency | 800 MHz |
|---|---|
| Operating temperature | 42K |
| Radial 5 G stray field from magnet center | 145 cm/57.1 in |
| System weight, operational | 4,000 kg/8,820 Ib |
| Minimum ceiling height (optional transfer) | 354 cm/139.4 in |
The system operates at 4.2 Kelvin.
The helium refill interval is greater than 120 days.
The magnet can be sited within a ceiling height of 3.54 meters (11.61 feet).
