The Agilent 7820A gas chromatograph system is a reliable instrument with a simplified user interface and display, suitable for routine analysis. It features full electronic pneumatics control and can be configured with different injectors and detectors. Various software options are available to help users maximize each run and workday.
The Agilent 7820A gas chromatograph is designed for routine analyses with minimized complexity, featuring a simplified front panel and full electronic pneumatics control (EPC) for all inlets and detectors. The system supports flexible software choices, including OpenLAB CDS ChemStation and EZChrom editions, to assist with data analysis and reporting.
Key technical specifications include an oven capable of temperatures up to 425 °C with five independent heated zones, and support for various detectors such as FID, TCD, ECD, NPD, and FPD. The system requires specific hardware and software configurations, such as the OpenLAB CDS platform, for complete control and data analysis.
| Height | 49 cm |
|---|---|
| Width | 56 cm |
| Depth | 51 cm |
| Average weight | 50 kg |
| Ambient operating temperature | 15 to 30 °C |
| Maximum oven temperature | 425 °C |
| Maximum operating temperature (Inlet) | 400 °C |
| Retention time repeatability | < 0.06% |
| Peak area repeatability | <2% |
| Maximum data acquisition rate (NPD) | up to 200 Hz |
The system is compatible with OpenLAB CDS ChemStation Edition, EZChrom Edition, OpenLAB CDS ChemStation VL, EZChrom VL, and OpenLAB CDS EZChrom Compact.
Available detectors include Flame ionization detector (FID), Thermal conductivity detector (TCD), Electron capture detector (ECD), Nitrogen phosphorous detector (NPD), and Flame Photometric detector (FPD).
The system supports voltages of 100 V, 120 V, 200 V, 220 V, 230 V, and 240 V with a frequency range of 47.5 to 63 Hz.
