Agilent PlateLoc Thermal Microplate Sealer is the premier thermal sealer for fast, easy, reliable microplate sealing
The Agilent PlateLoc Thermal Microplate Sealer is a premier instrument designed for fast, easy, and reliable microplate sealing. It accommodates a wide range of microplates, including deep well, assay, PCR, and compound storage types, through versatile plate stage inserts. The device features a touch-screen interface for controlling sealing time and temperature and supports robotic integration via RS-232 serial port and ActiveX control.
| Sealing Temperature | 30 to 200°C |
|---|---|
| Cycle Time | Approximately 8 seconds per plate |
| Warm-up Time | 2.5 minutes |
| Cool-down Time | 1 hour |
| Weight | 20 kg (45 lbs) |
| Dimensions (Height) | 58.4 cm (23") |
| Dimensions (Width) | 21.6 cm (8.5") |
| Dimensions (Depth) | 39.9 cm (15.7") |
| Operating Air Pressure | 6.2 bar (90 psi) |
| Operating Voltage | 100 — 120VAC, 50/60 Hz, 200 — 240VAC, 50/60 Hz |
The PlateLoc seals standard microplates in 96-, 384-, and 1536-well formats, including many deep well and PCR microplates.
No, a host computer is not required for manual operation, though Windows XP or Windows 7 is needed for VWorks Software.
The instrument comes with a 12-month warranty.
