National semiconductor COP87L88GD/RD Family 8-Bit CMOS OTP Microcontrollers with 16k or 32k Memory 8-Channel A/D with Prescaler handbook

COP87L88GD/RD OTP (One Time Programmable) Family microcontrollers are highly integratet COP8™ Fea- ture core devices with 16k or 32k memory and advanced features including an A/D Converter

Brand: National Semiconductor
Category: microcontrollers
Document type: Datasheet
Language: English
Pages: 39
File format: PDF
File size: 432 KB
Published: 04 July, 2012
Updated: 01 October, 2023
Model: COP87L88GD
MD5 checksum: A9D1D6719CFEDF05CA60F659C1F3422D
PDF: National semiconductor COP87L88GD/RD Family 8-Bit CMOS OTP Microcontrollers with 16k or 32k Memory 8-Channel A/D with Prescaler handbook PDF

About this manual

The COP87L88GD/RD Family consists of highly integrated One Time Programmable (OTP) microcontrollers designed for applications requiring a full-featured controller with an 8-bit A/D converter. These devices are available in two versions: the COP87L88GD with 16k EPROM and the COP87L88RD with 32k EPROM, both featuring 256 bytes of RAM and operating within a temperature range of -40°C to +85°C.

What's inside

General Description
Block Diagram
Connection Diagrams
Absolute Maximum Ratings
DC Electrical Characteristics
AC Electrical Characteristics
A/D Converter Specifications

Specifications

I/O Pins	40
Operating Voltage	2.7V to 5.5V
Instruction Cycle Time	1 µs (Crystal)
A/D Converter Channels	8-channel
Temperature Range	-40°C to +85°C
