National Semiconductor COP888EB 8-Bit CMOS ROM Based Microcontrollers with 8k Memory CAN Interface 8-Bit A/D USART handbook

COP888EB is a ROM-based microcontroller with 8k memory and advanced features including a CAN 2.0B (passive) interface, A/D, and USART. It is suitable for applications requiring a full-featured controller with a CAN interface, low EMI, and versatile communications interfaces.

Brand: National Semiconductor
Category: microcontrollers
Document type: Datasheet
Language: English
Pages: 75
File format: PDF
File size: 853 KB
Published: 04 July, 2012
Updated: 28 September, 2023
MD5 checksum: 577688E45D3A7995B53020FC799F0613
PDF: National Semiconductor COP888EB 8-Bit CMOS ROM Based Microcontrollers with 8k Memory CAN Interface 8-Bit A/D USART handbook PDF

About this manual

This document provides technical specifications for the COP888EB ROM-based microcontrollers. These devices feature an 8-bit memory-mapped architecture with up to 10 MHz clock speed, a CAN 2.0B passive interface, and an 8-channel A/D converter.

Key features include fully buffered USART, SPI master/slave interfaces, MICROWIRE/PLUS serial I/O, and two power-saving modes (HALT and IDLE). The microcontrollers are available in 44-pin and 68-pin PLCC packages with operating temperatures ranging from -55°C to +125°C.

What's inside

General Description
Key Features
DC Electrical Characteristics
Absolute Maximum Ratings
Applications

Specifications

Memory (ROM)	8k bytes
Memory (RAM)	192 bytes
Operating Voltage	4.5V to 5.5V
Clock Speed	10 MHz
Packages	44 PLCC, 68 PLCC

Frequently asked questions

What is the maximum operating voltage for this microcontroller?

The device operates with a supply voltage ranging from 4.5V to 5.5V.

How many interrupt sources are available on the COP888EB?

There are fourteen multi-sourced vectored interrupts servicing various functions.
