COP87L88CF 8-Bit CMOS OTP Microcontrollers with 16k Memory and A/D Converter
The COP87L88CF is a highly integrated 8-bit CMOS One Time Programmable (OTP) microcontroller designed for applications requiring a full-featured controller with an 8-bit A/D converter. It operates with a 10MHz clock and includes 16k bytes of on-board OTP EPROM and 128 bytes of RAM. The device supports a family of software and hardware development tools and is available in 28, 40, and 44-pin packages.
| Memory (OTP EPROM) | 16k bytes |
|---|---|
| RAM | 128 bytes |
| Operating Voltage | 2.7V to 5.5V |
| Instruction Cycle Time | 1 µs |
| A/D Converter Resolution | 8 Bits |
| A/D Channels | 8-channel |
| Timer Counters | Two 16-bit timer/counters |
| Temperature Range | -40˚C to +85˚C |
The instruction cycle time is 1 µs when using a crystal or resonator.
The device operates on a single supply voltage ranging from 2.7V to 5.5V.
Yes, it includes an 8-bit, 8-channel A/D converter with both differential and single-ended modes.
