The ADC0808M is a monolithic CMOS device with an 8-channel multiplexer, an 8-bit analog-to-digital (A/D) converter, and microprocessor-compatible control logic.
The ADC0808M is a monolithic CMOS device integrating an 8-channel multiplexer, an 8-bit successive-approximation A/D converter, and microprocessor-compatible control logic. It features ratiometric conversion, latched 3-state outputs, and no missing codes over its entire operating range.
The document provides absolute maximum ratings, recommended operating conditions, electrical characteristics, timing parameters, and principles of operation for the device designed to operate over a military temperature range of -55°C to 125°C.
| Resolution | 8 Bits |
|---|---|
| Total Unadjusted Error (Military Temp) | +/- 0.75 LSB Max |
| Supply Voltage | 4.5 V to 6 V |
The device has a resolution of 8 bits.
Yes, it is characterized for operation over the full military temperature range of -55°C to 125°C.
