The ADS1245 is a 24-bit, delta-sigma analog-to-digital converter (ADC). It offers excellent performance and very low power in an MSOP-10 package and is well suited for demanding high-resolution measurements, especially in portable and other space- and power-constrained systems.
The ADS1245 is a 24-bit, delta-sigma analog-to-digital converter (ADC) designed for demanding high-resolution measurements in portable and space-constrained systems. It features a high-impedance buffered input with a ±2.5V differential input range and operates from low-power supplies. The device includes simultaneous rejection of both 50Hz and 60Hz signals, single-cycle settling time, and self-calibration capabilities.
| Differential Input Range | ±2.5V |
|---|---|
| Analog Supply Voltage | 2.5V to 5.25V |
| Digital Supply Voltage | 1.8V to 3.6V |
| Current Consumption (Normal) | 158 µA |
| Data Rate | 15 SPS |
| Integral Nonlinearity (INL) | 0.0006% (typ), 0.0015% (max) |
The device outputs data at 15 samples per second (SPS).
Yes, it features single conversions with sleep mode to reduce power dissipation.
Yes, the device is designed to easily connect to microcontrollers such as the MSP430.
It is available in an MSOP-10 package.
