The ADS1605 is a high-speed, high-precision, 16-bit Δ-Σ analog-to-digital converter (ADC) with a data rate of 5MSPS and a signal-to-noise ratio of 88dB. It is suitable for applications such as scientific instruments, automated test equipment, data acquisition, medical imaging, and vibration analysis.
The ADS1605 is a high-speed, high-precision delta-sigma analog-to-digital converter (ADC) with 16-bit resolution and a data rate of 5MSPS. It features a bandwidth of 2.45MHz and offers outstanding performance with a signal-to-noise ratio up to 88dB and a spurious-free dynamic range up to 101dB. The device includes a selectable on-chip voltage reference and connects directly to TMS320C6000 DSPs via a simple parallel interface.
| Resolution | 16 Bits |
|---|---|
| Data Rate | 5.0 MSPS |
| Bandwidth | 2.45 MHz |
| Operating Temperature Range | -40 to +105 °C |
| Package | 64-pin TQFP |
The data rate is 5MSPS.
Yes, the input signal is measured against a voltage reference that can be generated on-chip or supplied externally.
The analog supply (AVDD) operates from +4.75V to +5.25V.
