The 74HC/HCT4075 is a high-speed Si-gate CMOS device with standard output capability and is categorized as SSI. It is pin compatible with the “4075” of the “4000B” series and is specified in compliance with JEDEC standard no. 7A. The 74HC/HCT4075 provides the 3-input OR function.
The Philips 74HC/HCT4075 is a high-speed Si-gate CMOS device that provides the 3-input OR function. It is pin compatible with the '4075' of the '4000B' series and is specified in compliance with JEDEC standard no. 7A.
The document details the device features, including output capability and Icc category (SSI). It includes quick reference data for propagation delay, input capacitance, and power dissipation capacitance. The datasheet also provides pin descriptions, a functional table, logic diagrams, and AC characteristics for both 74HC and 74HCT variants across various temperature ranges.
| Function | Triple 3-input OR gate |
|---|---|
| Standard Compliance | JEDEC standard no. 7A |
| Icc Category | SSI |
| Input Capacitance | 3.5 pF |
The device provides the 3-input OR function.
The device provides a 3-input OR function.
The unit load coefficient for inputs nA, nB, and nC is 1.50.
