Zetex ZXMN3A06DN8 Dual 30V N-Channel Enhancement Mode MOSFET Datasheet

ZXMN3A06DN8 is a dual 30V N-channel enhancement mode MOSFET from Texas Instruments, which features low on-resistance and fast switching speed, making it ideal for high efficiency, low voltage, power management applications.

Brand: Zetex
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 4
File format: PDF
File size: 55 KB
Published: 02 July, 2012
Updated: 30 September, 2023
MD5 checksum: E7103F2B88063FD382F9536AA90D22D4
PDF: Zetex ZXMN3A06DN8 Dual 30V N-Channel Enhancement Mode MOSFET Datasheet PDF

About this manual

The document describes the Zetex ZXMN3A06DN8, a dual 30V N-channel enhancement mode MOSFET designed with a unique trench structure. This design combines low on-resistance with fast switching speed, making it suitable for high-efficiency power management applications such as DC-DC converters and motor control.

What's inside

Summary
Ordering Information
Absolute Maximum Ratings
Thermal Resistance
Electrical Characteristics
Package Dimensions

Specifications

Drain-Source Voltage (V(BR)DSS)	30 V
Operating and Storage Temperature Range	-55 to +150 °C

Frequently asked questions

What are the applications for this MOSFET?

It is ideal for DC-DC converters, power management functions, disconnect switches, and motor control.

What is the package type?

The device uses a low profile SOIC package.
