This document describes the DM7438 and 7438 Quad 2-Input NAND Buffers with Open-Collector Outputs, introduced by Fairchild Semiconductor Corporation in 2000. The device contains four independent gates, each performing the logic NAND function. The open-collector outputs require external pull-up resistors for proper logical operation.
The document describes the Fairchild DM7438, an integrated circuit containing four independent gates that perform the logic NAND function. The device features open-collector outputs which require external pull-up resistors for proper logical operation.
This datasheet provides comprehensive technical data including absolute maximum ratings, recommended operating conditions, and detailed electrical characteristics such as input/output currents, supply current, and propagation delay times.
| Logic Function | Quad 2-Input NAND Buffers with Open-Collector Outputs |
|---|---|
| Propagation Delay Time (Typical) | 18 ns |
The device contains four independent gates each of which performs the logic NAND function.
Yes, the open-collector outputs require external pull-up resistors for proper logical operation.
