The ABT162244 is a 16-bit buffer/line driver that contains sixteen non-inverting buffers with 3-STATE outputs and 25-ohm series resistors. It can be used as a memory and address driver, clock driver, or bus-oriented transmitter/receiver. The device is nibble controlled, and individual 3-STATE control inputs can be shorted together for 8-bit or 16-bit operation. The 25-ohm series resistors in the outputs reduce ringing and eliminate the need for external resistors.
The document describes the ABT162244, a device containing sixteen non-inverting buffers with 3-STATE outputs. It is nibble controlled, allowing individual control of 4-bit sections or full 16-bit operation by shorting control inputs. The chip features 250 Series resistors in the outputs to reduce ringing and eliminate external resistor requirements.
| Number of Buffers | 16 non-inverting buffers |
|---|---|
| Output Type | 3-STATE outputs |
The device is nibble controlled, with individual 3-STATE control inputs that can be shorted together for 8-bit or 16-bit operation.
No, it includes internal 250 Series resistors in the outputs to reduce ringing and eliminate the need for external resistors.
