The MC68328 is a processor designed by Motorola which is integrated with a LCD controller and is suitable for many portable applications.
The MC68328 is an integrated portable system processor designed for the portable consumer market. It features a static 68EC000 core processor with full compatibility with the MC68000 and MC68EC000 families, offering 32-bit external and internal address buses capable of addressing 4GB of space. The processor operates at 3.3V with fully static HCMOS technology, allowing the clock to be stopped for dramatic power savings.
| Processor Core | Static 68EC000 Core Processor |
|---|---|
| Address Bus | 32-Bit External and Internal |
| Data Bus | 16-Bit On-Chip |
| Performance | 2.7 MIPS at 16.67-MHz |
| Operating Voltage | 5V or 3.3 V |
| Package | 144-Lead Thin Quad Flat Pack |
| I/O Ports | Up to 78-Bit |
It is designed for the portable consumer market to satisfy requirements for minimum components, small board space, low power consumption, and low system cost.
Yes, it is the first integrated processor of the 68K Family to include a LCD controller.
The processor operates from DC to 16.67 MHz.
