Yamaha M7CL Digital Mixing Console Supplementary Manual

About this manual

This supplementary manual explains the functionality changes and additions in version 2.0 of the M7CL firmware. It should be read in conjunction with the M7CL V1.1 supplementary manual and the M7CL Owner's manual. The document covers updates to HH Input and Output channel operations, input/output patching, EQ and Dynamics settings, Hi Grouping, Scene memory, Monitor/Cue controls, and User settings.

What's inside

• Main changes
• HH Input channel operations
• HH Output channel operations
• HH input/output patching
• EQ and Dynamics
• Hi Grouping and linking
• Scene memory
• Monitor/Cue
• User settings
• Channel library support

Frequently asked questions

What is the minimum threshold level for an input channel GATE?

The minimum threshold level for an input channel GATE is now -72 dB.

How many different settings can be recalled from the input and output channel libraries?

You can recall 200 different settings each from the input channel library and the output channel library.

How do you temporarily defeat linking for HA gain and fader operations?

Hold down the [SEL] key of the channel whose balance you want to adjust while operating the parameter.
