ADG3231 is a submicron-process, low voltage, single-channel level translator that operates from supplies as low as 1.65V. It is guaranteed for operation over the supply range 1.65V to 3.6V. It operates from two supply voltages, allowing bidirectional level translation, i.e., it translates low voltages to higher voltages and vice versa. The signal path is unidirectional, meaning data may only flow from A1 to Y1. This type of device may be used in applications requiring communication between different voltage levels.
The ADG3231 is a level translator designed on a submicron process that operates from supply rails as low as 1.65 V up to 3.6 V. It features bidirectional level translation capabilities, allowing it to translate signals between different voltage levels while maintaining a unidirectional signal path from input A1 to output Y1.
| Supply Voltage Range | 1.65 V to 3.6 V |
|---|---|
| Package Type | 6-Lead SOT-23 |
| Short Circuit Protection | Yes |
The device operates from supply rails ranging from 1.65 V to 3.6 V.
The 6-lead SOT-23 package requires a maximum of 5.28 mm X 5.28 mm board space.
The maximum DC output current is 25 mA.
