Agilent VS C15 Calibrated Leak Replacement Field Installation Instructions

About this manual

This document provides field installation instructions for replacing the calibrated leak assembly on a Varian (now Agilent) VS C15 Calibrated Leak Replacement unit. It includes safety warnings regarding solvents, static electricity, and high voltage, as well as specific procedures for handling O-rings and vacuum grease.

What's inside

• Hazard and Safety Information
• Solvents
• Vacuum Equipment and Cleanliness
• O-ring Care
• Equipment Required
• Installation Procedure

Frequently asked questions

What solvents are recommended for cleaning the leak detector?

Varian recommends VacuSolv solvent, or alternatively isopropyl alcohol (IPA) or Dow Corning OS-20.

What type of gloves should be worn when servicing the unit?

Non-powdered, ESD-safe Nitride or equivalent gloves must be worn to prevent skin oils from getting on internal components.

What grease is recommended for O-rings?

Varian recommends applying a small amount of Apiezon L grease and wiping the O-rings shiny dry.
