This is a user manual for Renesas Technology Corp.'s products.
The document is a technical specification sheet for the Renesas HZU Series Silicon Epitaxial Planar Zener Diodes. It details various models within the series ranging from 2.0V to 36V, including different grade options (B, B1, B2, B3) and their specific electrical parameters such as zener voltage, reverse current, and dynamic resistance.
The datasheet also covers ordering information, pin arrangements, absolute maximum ratings like power dissipation and junction temperature, and package dimensions for the Ultra Small Resin Package (URP). It notes that these devices are suitable for surface mount design and are delivered taped.
| Power dissipation (Pd) | 200 mW |
|---|---|
| Junction temperature (Tj) | 150 °C |
| Storage temperature (Tstg) | -55 to +150 °C |
| Package type | Ultra small Resin Package (URP) |
The standard grade B includes sub-grades B1, B2, and B3 depending on the specific model.
These diodes are delivered taped.
