Technical specifications for Renesas R3111x low‑voltage detector ICs, including features, electrical characteristics and package options.
The R3111x series are CMOS‑based low‑voltage detector ICs with high threshold accuracy and ultra‑low supply current. They integrate a voltage reference, comparator, resistor network for threshold setting, an output driver and a hysteresis circuit. The detector threshold is fixed internally and does not require external adjustment.
Three output configurations are offered (N‑channel open‑drain “L”, N‑channel open‑drain “H”, and CMOS) and the devices are available in seven package types, ranging from TO‑92 to SON1612‑6. The series operates from 0.7 V up to 10 V and is suitable for applications such as CPU reset, battery checking, window comparators and power‑failure detection.
| Supply Current (typical) | 0.8 µA |
|---|---|
| Operating Voltage Range | 0.7 V to 10.0 V |
| Detector Threshold Range | 0.9 V to 6.0 V (0.1 V steps) |
| Detector Threshold Accuracy | ±2.0 % |
| Output Types | N‑channel open‑drain “L”, N‑channel open‑drain “H”, CMOS |
| Maximum Supply Voltage (VDD) | 12 V |
| Maximum Output Current | 70 mA |
| Power Dissipation (TO‑92) | 300 mW |
| Available Packages | TO‑92, SOT‑89, SOT‑23‑3, SOT‑23‑5, SC‑82AB, SC‑88A, SON1612‑6 |
The typical supply current is 0.8 µA.
Three output types are offered: N‑channel open‑drain “L”, N‑channel open‑drain “H”, and CMOS.
They operate from 0.7 V up to 10.0 V at 25 °C.
The series is available in TO‑92, SOT‑89, SOT‑23‑3, SOT‑23‑5, SC‑82AB, SC‑88A and SON1612‑6 packages.
