Renesas EZ-CUBE attachment provides connection guidelines, pin configuration, switch settings, and flash‑programming instructions for 78K0 Core MCUs.
This document is an attachment to the EZ‑CUBE user manual and focuses on connecting the EZ‑CUBE emulator to Renesas 78K0 Core microcontrollers sold in China. It explains system composition, pin assignments, circuit examples, reset‑pin handling, switch configuration, online debugging steps, and flash‑programming procedures.
The guide also includes safety notices, export‑control warnings, and disposal instructions, ensuring users follow proper procedures when using the EZ‑CUBE for development and evaluation of 78K0 Core based designs. This manual is written in Chinese.
