This document is a standard drawing describing requirements for class H hybrid microcircuits to be processed in accordance with MIL-PRF-38534. It defines the Part or Identifying Number (PIN) structure, including specific device types such as ARX3419 and WHI-1523, along with their corresponding case outlines and lead finishes.
| Specification Compliance | MIL-PRF-38534 |
|---|---|
| Supply Voltage Range (Devices 02, 03, 04, 06, 09, and 10) | -11.6 V dc to +12.6 V dc |
| Receiver Differential Voltage | 80 Vp-p |
| Driver Peak Output Current (Devices 01, 03, 04, 06, and 10) | 200 mA |
| Storage Temperature Range | -65°C to +150°C |
The complete PIN includes the drawing number, device type, case outline, and lead finish.
These devices are processed in accordance with MIL-PRF-38534 for hybrid microcircuits.
