ACT9CSV-6 is a low power clock crystal from ACT, with a frequency range of 25.00~650.00MHz, operating temperature of 0~+70°C, and supply voltage of 3.3VDC ±5%
The ACTSCSV-6 is a family of 6-pad miniature surface mount Voltage Controlled Crystal Oscillators housed in a 7x5 mm ceramic package with a metal lid. Standing only 1.8mm high, these devices are ideal for high density automatic assembly printed circuit boards and can be pulled between +50ppm & +150ppm from the nominal frequency by varying the voltage on pad 1.
These oscillators support applications in Networking, Telecomms, PLL Circuits, Set Top Box, Audio Visual, and many other consumer applications. Key specifications include a frequency range of 25.00 to 650.00 MHz, an operating temperature range of -40 to +85°C, and supply voltage options of 3.3V or 5V.
| Package Type | 7x5 mm ceramic package with a metal lid |
|---|---|
| Height | 1.8mm |
| Frequency Range | 25.00 ~ 650.00 MHz |
| Pulling Range | +50ppm & +150ppm |
Applications include Networking, Telecomms, PLL Circuits, Set Top Box, Audio Visual and many other Consumer Applications.
The frequency stability ranges from +20ppm to +100ppm.
