This document describes the features and dimensions of ROHM's digital transistor products EMD9 / UMD9N / IMD9A.
This datasheet describes the ROHM dual digital transistors EMD9, UMD9N, and IMD9A, intended for inverter drive applications. It includes package information, marking codes, and ordering units for the EMT6, UMT6, and SMT6 package types.
Key electrical specifications are listed, such as supply voltage, input voltage range, output current, collector current, transition frequency, and temperature limits. The document also contains characteristic curves for two transistor variants (DTC114Y and DTA114Y) and a legal notice regarding usage and reproduction.
| Supply voltage (VEE) | 50 V |
|---|---|
| Input voltage (VIN) | 6 to +40 V |
| Output current (IO) | 70 mA |
| Collector current (IC) | 100 mA |
| Junction temperature (Tj) | 160 °C |
| Storage temperature (Tstg) | 56 to +150 °C |
| Transition frequency (fT) | 250 MHz |
The maximum supply voltage (VEE) is 50 V.
The input voltage can range from 6 V to +40 V.
The typical transition frequency is 250 MHz.
The specified storage temperature range is 56 °C to +150 °C.
